Siemens 14 Way Consumer Unit Set with a 50A RCBO and 14 MCBs
Siemens 14 Way Consumer Unit Set with a 50A RCBO and 14 MCBs - รายละเอียด
รายละเอียดสินค้า
Alpha Simbox 14 Ways 8GB3311-5TH01
5SU9354-7KK50 Main RCBO 2P 50A 10kA 30mA
Branch Circuit Breakers
MCB 1P 16A 6kA = 5 units
MCB 1P 20A 6kA = 6 units
MCB 1P 32A 6kA = 2 units
* The Main RCD (Residual Current Device) cannot be changed, but you can select the amperage for the branch breakers.
* You can inform the retailer of your selection via message.
The Siemens ALPHA SIMBOX Consumer Unit has been developed and designed using technology from Siemens, a global leader in innovation in energy and electronic engineering, thus ensuring the highest level of safety for users.
The Consumer Unit is used to house MCBs, RCBOs/RCCBs, and Surge Protection devices.
The cabinet is made from high-quality, extra-thick A-grade steel, providing high strength and durability, and is rust-resistant. It has a modern look and is designed for indoor installation in buildings and residences. It is manufactured according to international standards and TIS (Thai Industrial Standard) 1436-2540. Models are available with 4 to 20 circuits to suit various applications.
* The cabinet body is covered by a long-term 12-year warranty.
Residual Current Protective Device
Breaker for protection against Electric Shock - Earth Leakage - Overcurrent - Short Circuit (RCBOs)
The 5SU9 series RCBOs (protection against earth leakage/electric shock/overcurrent/short circuit) are devices that combine the features of RCCBs and MCBs. They can automatically trip the circuit when the leakage current value is 30 milliamperes (mA).
* Poles: 1P+N
* Rated Current Options: 10A, 16A, 20A, 25A, 32A, 40A
* Short-Circuit Capacity: 6kA and 10kA
* Rated Voltage: 230 V AC
Miniature Circuit Breakers (MCBs)
The new 5SL series branch circuit breakers (MCBs) are used to switch off electrical circuits to prevent overload and short circuits.
They are intended for installation inside Siemens Consumer Units and Load Centers and are suitable for use in all types of homes and residences.
Features the SLR (Slide Latch-Release) function, allowing individual breakers to be unlocked and removed from the circuit by hand without the need for tools.
* Poles: 1P
* Rated Current Options: 16A, 20A, 32A, 40A, 50A, 63A
* Maximum Short-Circuit Capacity: 6 kA / 10 kA
* Rated Voltage: 230/400 V AC
* Dimensions: 18 x 90 x 70 mm
* Standard: IEC/EN60898-1
